SonicTheHedgehog2Recomp

SonicTheHedgehog2Recomp

Save states

Open Escape -> Save states, choose slot 1–9, and save or load. Shift+F1…F9 saves; F1…F9 loads the corresponding slot. Files are native_save_<slot>.bin beside the executable. Quicksaves capture the next completed gameplay tick, including all four players, campaign session and widescreen objects. Levels, paused gameplay and special stages are supported; menus/loading/results are not save points. Loads can start from the title.

Keep the matching build and character/mod/video setup. Incompatible or damaged states are rejected before changing the game. Old machine-only quickstates are not compatible. Campaign SRAM remains the portable zone/act save format. Campaign quickstates must use the same selected campaign path; they rewind only the active slot, without overwriting other slots or immediately writing SRAM. These features are local-only.

Optional Sonic 3-style save menu

In Mods -> S3&K, enable Sonic 3-style Save Menu and select your original combined Sonic 3 & Knuckles ROM. This is disabled by default and independent of the Knuckles character option. The donor supplies menu artwork; Sonic 2 remains the running game.

Choose 1 PLAYER on the title screen for eight save files, No Save, and Delete. Files retain the zone and act, Chaos Emeralds, completion, and P1's lives/continues at campaign checkpoints. Completed files use Up/Down to choose any of the 20 acts (including Metropolis Act 3), cycling through CLEAR and Emerald Hill through Death Egg, and keep newly earned Emeralds. Portraits always show Sonic & Tails; actual characters come from Options. Left/Right selects a card, A/C/Start opens it, and B returns. Delete uses Robotnik's Yes/No sign: Left confirms, Right or B cancels; A/C/Start also confirms.

Occupied cards use numbered ZONE 01 through ZONE 11 captions and thumbnails decoded from your Sonic 2 ROM. There are no stage-name, act, file-number or character-arrow labels. A completed card starts with TV static and CLEAR; Up/Down picks a replay act and reveals its image. Cycling past either end returns to CLEAR; changing cards resets the temporary choice. Opening CLEAR without choosing resumes the file's stored destination. No extracted artwork is bundled. Changing cards or replay acts plays native Sonic 2 menu feedback inspired by Sonic 3; idle and blocked selections stay silent.

The bottom lives/continue icons always depict Sonic, independent of Options. Counters are saved with act/zone progress, Emerald awards and completion, not on every frame or life change. Loading restores those checkpoint values; a zero-life checkpoint restarts with three lives. No Save keeps native 3/0 defaults. Older version-1 campaign files load with 3 lives and 0 continues. The next changed checkpoint writes version 2, preserving the previous file as .bak; merely opening an old file does not rewrite it. All seven Emeralds appear only when all seven were collected: completion and Emerald collection are separate flags.

The mod's Campaign SRAM picker selects an existing Sonic 2 campaign save anywhere on disk. Saves load from and write back to that selected file, with a previous-revision .bak beside it. The picker starts empty on a fresh install; the first save creates sonic2-campaign.srm beside the executable and remembers its path. No Save creates no file. Paths inside the game folder are stored relative to the executable, so moving the folder keeps them working; external files retain their full paths. Clear selection returns to the default destination and preserves both files. Existing sonic2-campaign.sav files from the first version continue to load and save in place.

It does not patch the ROM or occupy emulated cartridge memory. Loading checks the file version, game identity, checksum, stage range and Emerald values before restoring known game fields. Invalid saves are preserved, and a valid backup can be opened read-only. Disabling the mod keeps your files. Campaign saves are local-only and cannot be combined with netplay. Compatible quickstates include the active campaign session, as described above.

Player 1 Super forms

Sonic, Tails, Amy and Knuckles can go Super as Player 1. Collect all seven Chaos Emeralds and at least 50 rings, then hold jump through the apex. Each character keeps their own sprites and abilities, with native Super speed, invincibility, ring drain and reversion. Knuckles still requires the enabled S3&K donor mod; Amy uses the existing Amy donor. Companions and native VS do not gain Super. Special stages always use stock Sonic and Tails. Death pits, crushing and drowning remain dangerous; this does not add Hyper forms or Super Flickies.

Source and validation: Player 1 Super forms.

Experimental widescreen mod

In the launcher's Mods page, enable Widescreen and choose Adaptive (fit window), 16:9, 21:9, or 32:9. The same controls are available in the in-game settings overlay. It is disabled by default; selecting an aspect alone does not enable it. Settings persist between launches.

This uses a Sonic-2-specific custom renderer through the shared framework's Sonic 1 mod interface. It reconstructs scenery from the real stage data, expands object spawning/culling and ring visibility, anchors the gameplay HUD to the screen, and keeps the selected canvas through title cards and fades. Adaptive follows live window resizing without a 32:9 cap; the practical limits are texture size, memory, and rendering cost.

While enabled, the mod also gives single-player level simulation extra CPU headroom so the wider active object range does not inherit the original hardware's slowdown. Physics still advances once per VBlank; music, DMA, interrupts and display timing retain their normal clocks. Disabling the mod restores native CPU timing.

For development, --widescreen fit, --widescreen 32:9, and --widescreen off override the saved selection. --widescreen stage requests the entire stage width; arbitrary ratios such as --widescreen 64:9 also work.

First-pass limitations:

• Special-stage scenery expands, but the half-pipe and its HUD retain the original centered projection.
• Native two-player competition keeps its original split-screen rendering; netplay disables the custom renderer.
• Extreme stage-length views can exhaust the original dynamic-object pool. Loading prioritizes objects nearest the player; rendering itself has no Genesis sprite-per-line limit.
• This is an experimental port, not a full-game/boss-route certification. Collision and stage decompression are unchanged, but expanded activation deliberately changes when off-screen enemies and objects begin updating.

Renderer details and input-only validation commands are in CUSTOM-VIDEO.md.

Netplay development

The native target opts into the shared segagenesisrecomp delay-sync runtime and the recomp-ui lobby flow. Build the SonicTheHedgehog2Recomp target, then launch two local peers with:

.\scripts\launch_netplay_pair.ps1

The host controls Sonic/player 1 and the guest controls Tails/player 2 using each process's player-1 device bindings. Use -Headless -Scenario Campaign -Frames 1200 for the primary Sonic & Tails synchronization test, or -Scenario Versus for the native split-screen gate. Hosted lobbies, LAN rooms, direct connections, and ICE use the same runtime frame-admission path.

During Sonic 2's native split-screen mode, each peer gets a full-window local view: the host/slot 0 sees the top (Sonic) viewport and the guest/slot 1 sees the bottom (Tails) viewport. The crop is presentation-only; deterministic framebuffer hashes and emulated state still contain the complete split frame.

Static recompilation port of Sonic the Hedgehog 2 (Genesis, 1992) to native C, sharing the recompiler / runner engine with SonicTheHedgehogRecomp. The native build is a clean-room implementation (own VDP / bus / Z80 scheduling, ymfm FM, permissively-licensed throughout); the AGPL clownmdemu core is a development-only conformance oracle and is never part of the shipped binary.

Status

Sonic 2 boots through the SEGA logo, reaches the title screen, and enters the attract demo.

Two-player versus mode works natively. Sonic 2's split-screen runs the VDP in interlace mode 2 (double vertical resolution: 448 lines, 8×16-pixel cells for planes and sprites, double-res sprite coordinates and vertical scroll). This is a consumed feature of the shared segagenesisrecomp engine: its clean-room VDP renders the full 448-line interlaced frame progressively — every line is a real rendered line, both fields, no squish hack.

Two presentation modes (engine feature, both correct):

• interlace_display=tv (default) — squashes 448→224 exactly like the original hardware looked on a TV; each player viewport appears vertically compressed, as on a real Genesis.
• interlace_display=raw — presents all 448 lines at full height: the window extends vertically and both player viewports display in proper 4:3 at full vertical detail. Sharper than original hardware could show; kept because we can.

Set the mode either via the CLI:

SonicTheHedgehog2Recomp.exe --interlace-display=raw

or by adding a line to debug.ini next to the .exe:

interlace_display=raw

1P gameplay is unaffected (non-interlaced rendering is unchanged).

Known behavioral differences (not defects)

• Special stages run ~2× faster than original hardware. The Sonic 2 half-pipe special stage was CPU-heavy enough to lag the original 68000, so its main loop effectively ran at ~30 Hz. The recomp executes the same code as native, never overruns the frame budget, and runs it at a full 60 Hz — technically more faithful to the code's intent, but it changes the tuned feel. This is a hardware-timing-fidelity gap (a future frame-lag-emulation enhancement), not a correctness bug. See ISSUES.md (ENH-1) for the measurements and analysis.

Layout

This repo owns Sonic 2's implementation: characters/AI, campaign and quickstate adapters, menu/image decoders, ROM configuration, disassembly, annotations and game tests. Only reusable framework code comes from the pinned segagenesisrecomp submodule:

SonicTheHedgehog2Recomp/                ← this repo
├── CMakeLists.txt                      ← Sonic 2 build wiring
├── game/                               ← Sonic 2 source + game.toml + annotations
│   └── s2disasm/                        ← pinned source disassembly submodule
├── tests/, tools/, docs/                ← game-owned validation and documentation
├── scripts/link-engine.{sh,bat}        ← optional shared-engine setup (local dev)
└── segagenesisrecomp/                  ← submodule (shared engine)
    ├── runner/                         ← shared runtime and opt-in interfaces
    └── recompiler/                     ← shared compiler, no Sonic 2 implementation

Generated C is ignored build output under build/generated/sonic2/, not a source-tree input.

CMake resolves the engine through the committed segagenesisrecomp submodule. For local dev across Sonic 1/2/3, an optional gitignored engine-local symlink (→ a single shared ../segagenesisrecomp checkout) takes precedence — see Build below.

Build

Prebuilt binaries are on the Releases page — supply your own ROM. You can also build from source below.

The engine is a git submodule, so a recursive clone is self-contained:

git clone --recursive https://github.com/mstan/SonicTheHedgehog2Recomp.git
cd SonicTheHedgehog2Recomp
# (cloned without --recursive? run: git submodule update --init --recursive)

ROMs and generated C are not bundled; the runtime uses the clean-room backend.

Builds natively on Windows (MSVC), macOS (Apple Silicon & Intel), and Linux. SDL2 is bundled on Windows; brew install sdl2 on macOS; libsdl2-dev on Linux.

Before configuring, copy your ROM to game/sonic2.bin. Generated C is not checked in; CMake builds the current recompiler and regenerates it from that ROM and the current discovery/configuration inputs before compiling the runner.

Windows (MSVC):

cmake -B build -S . -G "Visual Studio 17 2022" -A x64
cmake --build build --config Release
:: post-build copies SDL2.dll + annotations CSV next to the .exe
build\Release\SonicTheHedgehog2Recomp.exe build\Release\sonic2.bin

macOS / Linux (Ninja + Clang/GCC):

cmake -S . -B build -G Ninja -DCMAKE_BUILD_TYPE=Release
ninja -C build SonicTheHedgehog2Recomp
./build/SonicTheHedgehog2Recomp "path/to/Sonic the Hedgehog 2.bin"

Release packages (prod flags, netplay on, ROM never packaged). The version comes from git (git tag v0.8.2 first; off a tag it reads 0.8.2-3-g<sha>):

powershell -File tools\make_release.ps1   # release\SonicTheHedgehog2Recomp-windows-x64-v0.8.2.zip
bash tools/build-linux.sh                 # release-linux/SonicTheHedgehog2Recomp-linux-0.8.2-x86_64.AppImage

On Linux, drop sonic2.bin beside the .AppImage and run it; settings, campaign saves and quickstates are kept next to the .AppImage.

Local dev across games: to share ONE engine checkout instead of a per-repo submodule copy, clone segagenesisrecomp at the workspace root and run scripts/link-engine.sh (macOS/Linux) or scripts\link-engine.bat (Windows). CMake then prefers the gitignored engine-local symlink over the submodule.

Audio & video enhancements (opt-in)

The runner includes an optional verified-enhancement shadow layer — QoL audio/video improvements that run alongside the authentic hardware emulation and substitute only after continuously proving they still match it (reverting loudly if they ever stop). Off by default (output is byte-identical to raw hardware emulation); enable per-run via environment variables:

Variable	Values	Effect
GENESIS_SCREEN	raw (default), crt, trinitron, composite, linear	Present-time color model — maps the Genesis 9-bit gamut through a CRT/phosphor model (gamma + lifted black). raw is bit-identical passthrough.
GENESIS_AUDIO_SHADOW	0 (default) / 1	Arms the YM2612 FM shadow — a parallel ymfm chip with a relaxed output low-pass that keeps the cleaner, less-aliased highs.
GENESIS_FM_LADDER	unset (default) / off	With off, renders the FM shadow through ymfm's ladder-free ym3438 (no YM2612 DAC crossover crunch). Needs GENESIS_AUDIO_SHADOW=1.

GENESIS_AUDIO_SHADOW=1 GENESIS_FM_LADDER=off GENESIS_SCREEN=crt ./SonicTheHedgehog2Recomp sonic2.bin

Full design, verifier algorithm, and rationale: segagenesisrecomp/docs/SHADOW_ENHANCEMENTS.md.

Regenerate

regen.bat

Or use the configured build's generation target (also run automatically by a normal build):

cmake --build build --config Release --target genesisrecomp_generate_sonic2

The --reverse-debug flag enables rdb_on_block / rdb_on_insn hooks in the generated C, which power the crash_report execution trail (extremely useful for diagnosing freezes — points to the exact recompiled function and block when the watchdog fires).

Recent regen stats

[GenesisRecomp] Game config: 384 jump tables, 5023 extra funcs
[FunctionFinder] 4027 functions found
[FunctionFinder] Jump-table discovery: pc_indexed=349 manual=331 unresolved=22
[Codegen] Final function count after boundary splitting: 4425

22 unresolved PC-indexed dispatches remain — likely register-indirect or rare table shapes the static extractor doesn't recognize.

License

Releases ship under PolyForm Noncommercial 1.0.0 with permissive third-party components (ymfm BSD-3, superzazu z80 MIT, clowncommon ISC, SDL2 zlib) — see segagenesisrecomp/LICENSING.md and THIRD-PARTY-LICENSES.md. The AGPL clownmdemu core is used only by unshipped development/oracle builds. The Sonic the Hedgehog 2 ROM itself is not provided and must be obtained legally.

---
