TetrisGBRecomp

TetrisGBRecomp

Static recompilation of Tetris (Game Boy) for native PC. Built with the gb-recompiled engine and the shared recomp-ui launcher.

Status: Believed to be 100% playable. All game modes tested. Zero interpreter fallbacks with the Tier-0 seed manifest applied. If you find a bug, please open an issue.

What Works

• All game modes (A-Type, B-Type)
• Title screen, menus, demo/attract mode
• Music and sound effects
• recomp-ui launcher: ROM picker with CRC gate, settings/video/input overlay (F1)

ROM identity

The ROM is not embedded. On first run the launcher asks for one and gates it against game_get_expected_crc32() in extras.c:

Field	Value
CRC32	0x63F9407D
SHA-1	3f2a6407c9900ad5817ee1cfb3609c5ee17400fc
Size	32,768 bytes
Header title / version	TETRIS, mask-ROM version 0x00 (V1.0)

Common dump names: Tetris (World) / Tetris (W) (V1.0) [!].gb. The V1.1 revision (Tetris (JUE) (V1.1) [!], CRC32 0x46DF91AD) is a different program image and is not supported — the recompiled code comes from V1.0.

The accepted path is cached in rom.cfg next to the executable; delete it to re-pick.

Build & run

Dependencies

• Engine: gb-recompiled, cloned as a sibling directory (runtime_dir in the TOML points at ../gb-recompiled/runtime).
• Launcher: recomp-ui, also a sibling checkout. CMake auto-discovers it; override with -DRECOMP_UI_ROOT=<path>.
• Toolchain (Windows / msys2 mingw64): GCC, CMake, Ninja, SDL2. The build conflicts with devkitPro on PATH; export a clean PATH first.
• ROM: your own dump at roms/tetris.gb (see ROM identity).

Commands

export CLEAN_PATH="/c/msys64/mingw64/bin:/c/msys64/usr/bin:/c/Windows/system32:/c/Windows"

# 0. Build the engine once (in the gb-recompiled checkout).
PATH="$CLEAN_PATH" ninja -C ../gb-recompiled/build gbrecomp

# 1. Generate C from the ROM, driven by the TOML (+ harvested Tier-0 seeds).
PATH="$CLEAN_PATH" ../gb-recompiled/build/bin/gbrecomp.exe --config tetris.toml

# 2. Configure + build the generated project.
PATH="$CLEAN_PATH" cmake -G Ninja -S generated -B generated/build \
  -DCMAKE_C_COMPILER=/c/msys64/mingw64/bin/gcc.exe \
  -DCMAKE_CXX_COMPILER=/c/msys64/mingw64/bin/g++.exe \
  -DCMAKE_MAKE_PROGRAM=/c/msys64/mingw64/bin/ninja.exe \
  -DCMAKE_BUILD_TYPE=Release -DGBRECOMP_GENERATED_OPT_LEVEL=2
PATH="$CLEAN_PATH" ninja -C generated/build      # -> generated/build/Tetris.exe

# 3. Run it (SDL window; TCP debug server on 127.0.0.1:4370).
PATH="$CLEAN_PATH" ./generated/build/Tetris.exe

# 4. Harvest the run's interpreter fallbacks into the manifest, then GOTO 1.
PATH="$CLEAN_PATH" ../gb-recompiled/build/bin/gbrecomp.exe \
  --harvest generated/build/interp_fallbacks.log --manifest dispatch_misses.toml

Packaging a release

Ship the executable with assets/ (the launcher needs its fonts/images) and the mingw-w64 runtime DLLs: SDL2.dll, libEGL.dll, libGLESv2.dll, zlib1.dll, libgcc_s_seh-1.dll, libstdc++-6.dll, libwinpthread-1.dll. libEGL.dll is loaded dynamically by SDL/ANGLE, so ldd does not list it — omitting it fails at startup with "Could not load EGL library" on machines without msys2.

Always verify the packaged tree from a clean PATH before publishing, and confirm the CRC baked into the binary matches the ROM the release was generated from:

python -c "d=open('Tetris.exe','rb').read(); print(hex(d.find((0x63F9407D).to_bytes(4,'little'))))"

Controls

GB Button	Keyboard
D-Pad	Arrow keys
A	Z
B	X
Start	Enter
Select	Right Shift

Hotkey	Action
F1	recomp-ui overlay (settings, video, input, mods)
TAB (hold)	Turbo (fast-forward)

Rebind in the overlay or edit keybinds.ini next to the executable.

Architecture

This is a static recompiler, not an emulator. The original SM83 (Game Boy CPU) machine code is translated to C at build time, then compiled to native x64. The Game Boy PPU, APU, and memory mapper are simulated by the runtime library.

What's in this repo

Path	Purpose
tetris.toml	Recompiler config: ROM path/CRC, output, entry points, HRAM overlay
dispatch_misses.toml	Tier-0 manifest: harvested zero-FP function-entry seeds (auto-ingested)
extras.c	Game hooks: expected CRC32, launcher name, gb (DMG) platform
recomp/launcher/boxart.tga	Launcher card art
README.md	This file

Not tracked (regenerable or external): generated/ (recompiler output + build tree), roms/ (the ROM), logs/, interp_fallbacks.log, and the gb-recompiled / recomp-ui checkouts (pinned as submodules, junctions locally).

Hard rules (inherited from the engine project)

• Zero false positives in code discovery. Decoding data as code is a failure. Trace-harvested seeds are safe because they provably executed.
• Never edit generated code (generated/*.c). It's a build artifact — fix the engine and regenerate.
• Ghidra before guessing runtime/crash behavior (engine RULE 0).

---
