Vandal Hearts PC

Vandal Hearts PC brings Vandal Hearts to PC.

README

cover-pc-port

Vandal Hearts — Native PC Port

A native PC port of the PlayStation 1 game Vandal Hearts, built on byte-exact matching decompilations of the game. One executable runs the USA (SLUS-00447), Asia (SCPS-45183) and Japan (SLPM-86007) releases — drop in whichever disc you own and the region is auto-detected.

Non-commercial fan preservation project. Not affiliated with Konami or Sony. You must supply your own legally-owned copy of the game. See DISCLAIMER and Legal below.

The project has three stages, all completed:

  1. Matching decompilation. Every non-PsyQ function is decompiled to C that rebuilds the original executable byte-for-byte, verified by make check on every change — the US SLUS_004.47 (md5 596bb082a2de5f1fe977dd3d7e160b03) and, since 2.0.0, the Japanese SLPM_860.07 (md5 53849277b08184863bd45f10925995a6) from its own decompiled tree. This is the foundation the port is built on, and it is still enforced on every change.

  2. De-consolization → native PC port. Each PlayStation hardware interface — GPU packet submission, GTE matrix math, CD-ROM / XA audio, SPU, MDEC video, pad input — is replaced with a portable equivalent (SDL2 + Metal/OpenGL + OpenAL), so the game boots and runs on a modern desktop from its own data.

  3. New features. A PC-only layer of additions on top of the faithful port: reworked controls with an at-a-glance enemy threat overlay, an in-game options and save-management overlay, an opt-in Tactical Mode rebalance that offers a fresh way to play, a higher-fidelity graphics track (an accurate software rasterizer with optional internal-resolution supersampling), and an optional HD pack for backgrounds and movies, plus a translation framework that lets the community author and load language packs. The faithful retail experience stays the default; anything that changes gameplay is opt-in. See:

Status

The port runs the full game end-to-end from the original data — intro FMVs, cutscenes, tactical battles, world map, party management, dialogue, shops, and save/load — validated by full playthroughs on both Windows and Linux, including the endgame and credits.

  • All three regional discs, one executable (v2.0): USA, Asia and Japan releases are auto-detected (put any or all of them in game/); with several discs installed, the in-game DISC option switches between them. The Japanese game runs with the full PC feature set — Tactical Mode, the options overlay, HD pack support, fast-forward — with its own faithful Japanese text. Language packs remain a US-disc feature by design.
  • A/V fidelity: complete, validated against real hardware (BizHawk): GTE/perspective and terrain/sprite rendering; a sample-accurate software SPU driving the SEQ music and VAG sound effects; CD-XA streamed audio; MDEC/STR video; and PS1 Shift-JIS/kanji text.
  • Graphics fidelity (v1.5): the software renderer is a PSX-accurate integer rasterizer (exact GPU coverage + texture sampling, dithering, 5-bit blend; ~99.8–99.99% pixel-exact vs a reference-emulator capture), with optional internal-resolution supersampling (1–4×) on a multithreaded high-res pass for a sharper image with no re-authored art. The faithful look is the default.
  • Optional HD packs (v1.6, per-region since v2.0): an opt-in layer that replaces the pre-rendered backgrounds and the FMV movies with higher-resolution art (.webp + HEVC), auto-detected beside the executable and toggled by the HD PACK option. Packs are per game disc under hdpacks/<game-id>/ — one for the US/Asia master, one for the Japanese game (its movies carry burned-in Japanese subtitles). The source tree and base build ship no art — a pack is either built offline from your own disc or downloaded as an optional release asset; the base build is unchanged without one. See docs/hd-pack.md.
  • 64-bit is the default build. The port is memory-safe — it runs unprivileged (no root, no setcap) and has passed both an AddressSanitizer out-of-bounds sweep and a UBSan pass across the game, which together fixed seven real out-of-bounds bugs latent in the retail game.
  • Platforms: Windows and Linux (fully supported, full-playthrough validated), plus a community-supported, experimental macOS build, all from a single source tree. The Windows .exe is cross-compiled from Linux with MinGW-w64; Linux ships as an AppImage. The native macOS CMake build (a community contribution — the maintainer has no Apple hardware) has been tested on Apple Silicon through the first battle and its surrounding cutscenes, world map, towns, shops, saves, Tactical Mode, fast-forward and HD pack; a dependency-minimal Universal 2 build has passed boot-to-title in both native arm64 and x86_64/Rosetta modes, and source-only local .app packaging is available. Full-playthrough and notarisation validation remain to be done. See docs/cross-platform.md.

Where to start

You want to…Go to
Play the gameGrab the latest release — the Player Manual (PDF) ships with it and covers setup, controls, and every feature (source). Quick start below.
Something's wrongTroubleshooting · Known issues · then open an issue.
Translate the gameLanguage packs — what they cover and how they install — then the authoring toolchain: hands-on quickstart · full reference.
Contribute / fix a bugArchitecture first — the two-layer design and the one unbreakable rule — then CONTRIBUTING.md.
Understand how it worksThe documentation index: internals, subsystem deep-dives, decoded game mechanics.

Community language packs

Packs made by the community, hosted by their authors. They are not part of this project and are not reviewed by it. Report problems with a pack on its own tracker. Install instructions are in docs/language-packs.md.

LanguageCreatorLink
Spanisharcadematicashttps://github.com/arcadematicas/traduccion-vandal-hearts-decompiled-espa-ol

Quick start

You supply the game; the port supplies everything else. You need your own legally-owned copy of Vandal Hearts — USA (SLUS-00447), Asia (SCPS-45183) or Japan (SLPM-86007) — dumped as a raw .bin disc image — nothing game-derived is distributed here.

PlatformPackageRequirements
Windows.zip — vandalhearts_pc.exe, 8 runtime DLLs, vandalhearts.iniWindows 10/11
LinuxVandalHearts-x86_64.AppImage + vandalhearts.iniglibc ≥ 2.34 (Debian 12+, Ubuntu 22.04+, Fedora 35+, RHEL 9, Arch); FUSE2
macOS (community-supported, experimental)Build from source — no macOS release assets heremacOS 11+; Universal 2 base build or Apple Silicon HD build

This repository provides releases for Windows and Linux. The macOS build is community-supported and built from source (docs/cross-platform.md). macOS builds might be provided by community members on their own forks — those are outside this project's scope and are not verified or supported here.

Put your disc image (any supported region, or several) in a game/ folder next to the executable and launch — each disc is auto-detected and verified, and with more than one installed the in-game DISC option switches the active game (applies on restart). Settings live in the in-game overlay (SELECT + START) and vandalhearts.ini, and saves are plain files in saves/ (per region — US and Japanese saves are separate). Details: the Player Manual, configuration.md, and platform/pc/OPTIONS.md.

Building from source

No game executable, disc image, Sony BIOS/SDK data, or in-game text is distributed here. They are git-ignored and must come from your own legally-owned copy; the build reconstructs what it needs locally. (The repo does contain the decompiled game code and a few functional game-data tables — see Legal and NOTICE.)

cd platform/pc && make unified    # the release binary (all regions) -> build-uni/vandalhearts_pc
cd platform/pc && make link       # single-region dev build          -> build/vandalhearts_pc
make check                        # (repo root) US byte-exact decomp verification -> MD5 must match
cd jp && make check               # Japanese byte-exact decomp verification

(Native deps: SDL2/OpenAL/GL/libwebp/libav, Python 3.)

The full picture — CMake, the Windows cross-compile, the AppImage container, sanitizers, and the matching-decomp toolchain — is in building.md and cross-platform.md. Any change under src/ or include/ must keep make check passing (architecture.md has the gating rules).

Documentation

Full developer and user documentation is in docs/. Contributions and bug reports are welcome — see CONTRIBUTING.md for the ground rules (above all: the matching build must stay byte-exact).

Repository layout

The repository root is the matching-decompilation layer, kept in the standard splat-decomp shape — Makefile (make check), SLUS_004.47.yaml, and the symbol map at top level, exactly where anyone from the decomp scene expects them (and where the upstream decompilation keeps them). The port lives entirely under platform/pc/.

  • src/, include/ — the US matching decompilation (C source and project headers).
  • jp/ — the Japanese matching decompilation (SLPM_860.07), same shape (own make check); most files are shared with the US tree and verified identical at build time.
  • SLUS_004.47.yaml, undefined_additional.txt — splat configuration and linker symbol input.
  • symbol_addrs.txt — the address → symbol map. Shared ground truth, not decomp-only: the port's data-segment generator reads it on every port build.
  • platform/pc/ — the native PC port: PSX subsystem backends (src/lib*.c, pc_*.c), the build system (Makefile, CMake, cmake/ toolchain files), data-generation and sanitizer tooling (tools/, run_*san.sh), release packaging (packaging/), and clean-room PsyQ headers.
  • docs/ — developer & user documentation.

Some data files are generated at build time from your own copy and are not committed (e.g. the PS1 kanji font from KROMDAT.BIN, and the in-game description strings) — the same model as the data segment. See NOTICE.

Legal

This is a non-commercial fan preservation and interoperability project, not affiliated with or endorsed by Konami or Sony, not sold, and generating no profit.

  • Vandal Hearts and all related IP are © Konami. The PlayStation, its BIOS, and the PsyQ SDK are © Sony. No ownership of either is claimed.
  • Not in this source repository: the game executable, a disc image, Sony BIOS/SDK data (including the PS1 kanji font), Konami's in-game text, or any extracted assets. Supply your own game copy; the build reconstructs what it needs locally.
  • Present in the repo: the reverse-engineered decompilation of the game code (src/), and a small number of functional game-data tables (unit stats, animation/sprite pointer tables) reconstructed from the binary — included for interoperability and preservation, © Konami, not claimed as this project's own.
  • Pre-built release binaries do embed a portion of game-derived data (the executable's static data segment, a small BIOS-derived kanji font, and the reconstructed text/data tables), because a compiled binary bakes in what the source tree regenerates locally. This is only a fraction of the game — dialogue, maps, audio, and video load at runtime from the disc you supply, so a release binary does nothing without your own legally-owned copy. Full breakdown in NOTICE.

Full detail in DISCLAIMER.

License

The original PC-port code and tooling written for this project (principally platform/pc/) are licensed GPL-2.0 (see LICENSE). This does not extend to the decompiled game code or the game-derived data, which are Konami's and are not the project's to license — see NOTICE for exactly what the GPL-2.0 grant covers and what it does not.

Credits

Built on the Vandal Hearts matching decompilation by shao113 (https://github.com/shao113/vh). Full acknowledgements — the decomp toolchain (splat, maspsx, old-gcc), the psx-spx hardware reference, and BizHawk — are in CREDITS.

External files (supply from your own copy)

Not included in this repository:

filemd5
SLUS_004.47 (US base executable)596bb082a2de5f1fe977dd3d7e160b03
SLPM_860.07 (Japanese base executable)53849277b08184863bd45f10925995a6
ASPSX.EXE (ASPSX v2.21, PSYQ v3.3 / DTL-S2190)e3ae8aea2623b916f89384bf70f55487
LIB34.ZIPd25fd757e944a05369e8fb003a007dd2
